��(xiàng)��?jī)?nèi)��

Item Contents

M1432x1000

M1432x1500

工作��(tái)上最大回��(zhuǎn)直徑（mm��

Max.grinding diameter on table

Φ360

Φ360

兩頂尖最大距離（mm��

Max. distance between two centers

1000

1500

卡盤夾持承載重量（Kg��

Max.chuck load

40

40

頂尖間最大承載重量（Kg��

Max.load between two centers

130

外圓磨削范圍（mm��

Max. external grinding diameter and length

(Φ8-Φ320)x1000

(Φ8-Φ320)x1500

��(nèi)孔磨削范圍（mm��

Internal grinding diameter

Φ30-100

最大磨削內(nèi)孔深度（mm��

Max.internal grinding depth

125

頭架頂尖孔（Morse��

Spindle taper of headstock

MT.5

尾架頂尖孔（Morse��

Spindle taper of tailstock

MT.5

外圓砂輪尺寸（外�� x �� x ��(nèi)孔）（mm��

External grinding wheel size

Φ400x40xΦ203

砂輪架��(jìn)給手輪每��(zhuǎn)��(jìn)給量（mm��

Per rev. feeding value of grinding wheel

�� 2

��(xì) 0.5

砂輪架��(jìn)給手輪每格��(jìn)給量（mm��

Per grad. feeding value of grinding wheel

�� 0.01

��(xì) 0.0025

砂輪主軸電機(jī)（KW��

Motor of grinding wheel spindle

5.5

主軸��(zhuǎn)速（r/min��

Spindle speed

1440

��(nèi)圓磨削電��(jī)（KW��

Motor of internal grinding spindle

1.1

��(nèi)圓電��(jī)��(zhuǎn)速（r/min��

Motor speed of internal grinding spindle

3000

頭架主軸電機(jī)（KW��

Motor of headstock grinding spindle

0.75

頭架��(zhuǎn)速（r/min��

Motor speed of headstock grinding spindle

0-320

砂輪架回��(zhuǎn)角（°��

Turning angle of grinding wheel

30

工作��(tái)回轉(zhuǎn)角（°��

Turning angle of worktable

-3��+9��+7��+6

總電源功率（KW��

Total drive capacity

9

圓度（mm��

Roundness

外圓 0.003

��(nèi)�� 0.0035

柱度（mm��

Cylindricity

外圓 0.0055

��(nèi)�� 0.007

表面粗糙度（um��

Surface roughness

外圓 Ra �� 0.16

��(nèi)�� Ra �� 0.63

��(jī)床凈重（Kg��

Net weight/Gross weight

3300

3800

��(jī)床尺寸（��(zhǎng) x �� x 高）（mm��

Packing dimension

3200x1800x1420

4200X1800X1420
